0HP Modular Giveaway!

Hey folks, we are giving away some of our new products! All you have to do is like our page and share this image on Facebook (link is: http://tinyurl.com/y822cl2g), or sign up for our mailing list, or enter twice by doing both! First prize winner will get a 0HP module of their choice with a rare color backing of their choice, second place winner will get a 0HP module of their choice with normal color backing of their choice, third place winner gets a pair of blinkenlite multipliers. You can sign up for our mailing list on the right hand side of this page. Winners will be chosen Wednesday next week. Good luck! <33

Thursday, July 20, 2017

0HP Modular is now available!


Our newest modular offering sits outside of the case, saving you time, space, power and cash!  Our first two modules are logic gates but they can be used for all kinds of voltages.  Take a look at our product page for more.

Monday, April 24, 2017

Fixed an issue with our contact form

Just making sure people know that we were not ignoring you, there was an issue with the contact form which was set up for the old name and old email.  We will be going through older emails and contacting people, sorry for the hassle.

Thursday, April 6, 2017

Mystic Circuits has landed in Europe

We at Mystic Circuits are pleased to announce our first international retailers!

For assembled modules, please visit Schneidersladen at http://www.schneidersladen.de/en/manufacturer/mystic-circuits.html

For DIY options, please visit Thonk at https://tinyurl.com/MysticDIY

Tuesday, January 24, 2017

NAMM 2017 after party

We aren't listed on the flier but I promise that we will be at Analogue Haven tonight showing off our gear.  Come by and say hello!

Monday, December 19, 2016

DIY kits now on sale

Just in time for you to get yourself a holiday gift the SPECTRA MIRROR is now available in DIY options. We have also lowered the prices on our older DIY kits for the VERT and SWITCHES expander. Heat up that soldering iron to stay warm this winter!

Spectra Mirror DIY options now available.

At long last here is the build documentation and BOM required to support a DIY build of the Spectra Mirror.  The entire build is through hole with easy to find parts, there is one optional SMD matched transistor pair for those wanting superior tracking of the internal VCO.  I would say that this project is not for a complete beginner but would be quite easy for anyone with a fair amount of DIY experience.  The calibration procedure requires at least a multimeter and benefits from the use of an oscilloscope, although again this is not crucial.  Please read the build documentation if you want a better idea of the level of difficulty for the build.

Build documentation is here.

Support/ discussion thread is here.

Mouser BOM is here.  A few parts have to be bought from other places as listed below:

100K B metal shaft potentiometers x 7 : several options exist

100k B plastic shaft potentiometer x 3 : you want to buy the "tall trimmer" from song huei as others do not stick very far out of the panel.  Plus these pots have a painted indicator.

"Erthenvar" PJ301-B style jacks x 12 : be sure to buy matching washers

Knobs x 7 : You can buy whichever knobs you like but this is the source for the purple ones that I use.  If anyone knows a European distributor for these knobs let me know and I will add them to this list.  Color option is violet

Large knob x 1.  If you are using other knobs I still suggest using a large knob for this dial.  Again color is violet.


The following parts will be needed.  I am specifically making you source them as a "barrier for entry" as doing this matched transistor pair is not for DIY beginners.  SMD soldering aptitude is required.

Transistor pair is by diodes incorporated part # ZXTC2045E6TA

You will also need a 22k resistor and a 22nF capacitor.
